Launch X431 BST360 Bluetooth Battery Tester Used with all Launch devices, Xpro5

Description

🏁 Overview

The BST360 combines advanced testing algorithms with Bluetooth connectivity to provide complete insights into a vehicle’s electrical system.
Designed for workshops, service centers, and mobile technicians, it performs battery health, start system, and charging system tests with precision and speed.
Compact, safe, and intuitive, the BST360 ensures professional accuracy while remaining simple enough for on-the-go checks.
It’s the ideal companion for every Launch diagnostic platform, extending functionality beyond standard OBD diagnostics.

⚙️ Main Test Functions

Battery Health Test
Evaluates the battery’s actual cold cranking capacity (CCA) and determines the aging level. Provides a detailed status report for preventive maintenance and accurate battery replacement decisions.

Smart System Test
Analyzes the starter motor’s performance, measuring starting current and voltage drop during ignition to assess overall functionality and system health.

Charging Health Test
Monitors the alternator’s output voltage, charging current, and rectifier diode performance. Identifies irregularities in the charging system to prevent power loss and overcharging issues.

Start System Test
Provides a deeper evaluation of the starter’s load and system reaction time, helping technicians identify electrical or mechanical failures early.

🟡 Features & Advantages

• Bluetooth Wireless Connection – automatic pairing with Launch or XPRO5 devices for seamless data transmission.

• Safe, Spark-Free Testing – no heat generation or operational risks, ensuring maximum safety.

• Compact and Portable – pocket-sized, rugged design for both workshop and mobile use.

• Instant Results – plug in and test directly, even on low-voltage or discharged batteries.

• Reverse Polarity Protection – safeguards both the tester and the vehicle from incorrect clip connection.

• Battery Type Compatibility: standard, AGM start-stop, GEL, and EFP batteries.

• Supported Battery Standards: CCA, BCI, CA, MCA, JIS, DIN, IEC, EN, SAE, GB.

• Report Generation & Sharing: automatic result reports viewable on Android/iOS apps, with one-tap Bluetooth sharing.

• Multi-Language Interface: English, German, French, Italian, Spanish, Portuguese, Russian, Japanese, Chinese, and more.

Every feature is optimized for reliability, safety, and user convenience — making the BST360 a professional-grade testing companion.

🚦 Technical Specifications

Test Range: 100–2000 CCA
Voltage Range: 6–16 V DC
Working Temperature: -20°C to 60°C
Communication: Bluetooth BLE 4.0
Power Supply: From battery under test
Display & Control: Via Launch/XPRO5 device or mobile app (Android/iOS)
Standards Supported: CCA, BCI, CA, MCA, JIS, DIN, IEC, EN, SAE, GB
Battery Types: Regular, AGM Start-Stop, GEL Start-Stop, EFP Start-Stop
Protection: Reverse polarity and overvoltage protection
Dimensions: 125 × 75 × 25 mm

🏁 Why It Matters

The Launch X431 BST360 helps workshops prevent electrical issues before they become costly failures.
It delivers accurate diagnostics for battery health, charging systems, and starting performance in under a minute — without removing the battery.
For technicians, it means faster testing, clear reports, and professional credibility.
For customers, it means confidence that every inspection is data-backed and verified.

⚙️ Package & Purchase Information

• 1 × Launch X431 BST360 Battery Tester

• 1 × User Manual (English)

• 1 × Quick Start Guide

• 1 × Carrying Box

• 1 × 12-Month Warranty
